Container-based image renderer not fully working with Grafana behing Apache proxy

szymontrocha · May 15, 2026, 11:09am

Hi,

What Grafana version and what operating system are you using?
- Stand-alone 11.6.10, Debian 12
What are you trying to achieve?
- Have Grafana image rendering working
How are you trying to achieve it?
- I have stand-alone Grafana running and then deployed container version of grafana-image-renderer (in the same host)
- Grafana is running behind Apache proxy
- There is a SSL certificate configured in Apache
- There is a service account in Grafana with token generated

What happened?

The workflow partially works:

Grafana seems to be able to send request to renderer and it seems to be accessible from the server:

$ curl -v http://localhost:8081/render/version
*   Trying 127.0.0.1:8081...
* Connected to localhost (127.0.0.1) port 8081 (#0)
> GET /render/version HTTP/1.1
> Host: localhost:8081
> User-Agent: curl/7.88.1
> Accept: */*
>
< HTTP/1.1 200 OK
< Content-Type: application/json
< Date: Fri, 15 May 2026 10:22:27 GMT
< Content-Length: 20
<
* Connection #0 to host localhost left intact
{"version": "5.0.0"}

$ curl -v -H "Authorization: Bearer ***" "https://foo.bar/grafana/render/d-solo/feizqmmy116gwe/?orgId=1&from=2026-04-12T09:22:17.007Z&to=2026-05-12T10:22:17.007Z&panelId=1" -o chart.png
  % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                 Dload  Upload   Total   Spent    Left  Speed
  0     0    0     0    0     0      0      0 --:--:-- --:--:-- --:--:--     0*   Trying my_ip:443...
* Connected to foo.bar.pl (my_ip) port 443 (#0)
* ALPN: offers h2,http/1.1
} [5 bytes data]
* TLSv1.3 (OUT), TLS handshake, Client hello (1):
} [512 bytes data]
*  CAfile: /etc/ssl/certs/ca-certificates.crt
*  CApath: /etc/ssl/certs
{ [5 bytes data]
* TLSv1.3 (IN), TLS handshake, Server hello (2):
{ [122 bytes data]
* TLSv1.3 (IN), TLS handshake, Encrypted Extensions (8):
{ [25 bytes data]
* TLSv1.3 (IN), TLS handshake, Certificate (11):
{ [5097 bytes data]
* TLSv1.3 (IN), TLS handshake, CERT verify (15):
{ [264 bytes data]
* TLSv1.3 (IN), TLS handshake, Finished (20):
{ [52 bytes data]
* TLSv1.3 (OUT), TLS change cipher, Change cipher spec (1):
} [1 bytes data]
* TLSv1.3 (OUT), TLS handshake, Finished (20):
} [52 bytes data]
* SSL connection using TLSv1.3 / TLS_AES_256_GCM_SHA384
* ALPN: server accepted http/1.1
* Server certificate:
* <cert-details-cut-off>
*  SSL certificate verify ok.
* using HTTP/1.1
} [5 bytes data]
> GET /grafana/render/d-solo/feizqmmy116gwe/?orgId=1&from=2026-04-12T09:22:17.007Z&to=2026-05-12T10:22:17.007Z&panelId=1 HTTP/1.1
> Host: foo.bar
> User-Agent: curl/7.88.1
> Accept: */*
> Authorization: Bearer ***
>
{ [5 bytes data]
* TLSv1.3 (IN), TLS handshake, Newsession Ticket (4):
{ [57 bytes data]
* TLSv1.3 (IN), TLS handshake, Newsession Ticket (4):
{ [57 bytes data]
* old SSL session ID is stale, removing
  0     0    0     0    0     0      0      0 --:--:--  0:00:04 --:--:--     0{ [5 bytes data]
< HTTP/1.1 200 OK
< Date: Fri, 15 May 2026 10:53:23 GMT
< Server: Apache/2.4.67 (Debian)
< Accept-Ranges: bytes
< Cache-Control: private
< Content-Length: 44155
< Content-Type: image/png
< Last-Modified: Fri, 15 May 2026 10:53:23 GMT
< X-Content-Type-Options: nosniff
< X-Frame-Options: deny
< X-Xss-Protection: 1; mode=block
<
{ [7875 bytes data]
100 44155  100 44155    0     0   9106      0  0:00:04  0:00:04 --:--:--  9107
* Connection #0 to host foo.bar left intact

from within the container also Grafana seems to be accessible (test done from container)

$ curl -I https://foo.bar/grafana/
HTTP/1.1 200 OK
Date: Fri, 15 May 2026 10:32:41 GMT
Server: Apache/2.4.67 (Debian)
Cache-Control: no-store
Content-Type: text/html; charset=UTF-8
X-Content-Type-Options: nosniff
X-Frame-Options: deny
X-Xss-Protection: 1; mode=block

curl -v -H "Authorization: Bearer ***" "https://foo.bar/grafana/d-solo/feizqmmy116gwe/?orgId=1&from=2026-04-12T09:22:17.007Z&to=2026-05-12T10:22:17.007Z&panelId=1" | more
  % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                 Dload  Upload   Total   Spent    Left  Speed
  0     0    0     0    0     0      0      0 --:--:-- --:--:-- --:--:--     0* Host foo.bar:443 was resolved.
* IPv6: (none)
* IPv4: my_ip
*   Trying my_ip:443...
* ALPN: curl offers h2,http/1.1
} [5 bytes data]
* TLSv1.3 (OUT), TLS handshake, Client hello (1):
} [1584 bytes data]
*  CAfile: /etc/ssl/certs/ca-certificates.crt
*  CApath: /etc/ssl/certs
{ [5 bytes data]
* TLSv1.3 (IN), TLS handshake, Server hello (2):
{ [122 bytes data]
* TLSv1.3 (IN), TLS change cipher, Change cipher spec (1):
{ [1 bytes data]
* TLSv1.3 (IN), TLS handshake, Encrypted Extensions (8):
{ [25 bytes data]
* TLSv1.3 (IN), TLS handshake, Certificate (11):
{ [5097 bytes data]
* TLSv1.3 (IN), TLS handshake, CERT verify (15):
{ [264 bytes data]
* TLSv1.3 (IN), TLS handshake, Finished (20):
{ [52 bytes data]
* TLSv1.3 (OUT), TLS change cipher, Change cipher spec (1):
} [1 bytes data]
* TLSv1.3 (OUT), TLS handshake, Finished (20):
} [52 bytes data]
* SSL connection using TLSv1.3 / TLS_AES_256_GCM_SHA384 / x25519 / RSASSA-PSS
* ALPN: server accepted http/1.1
* Server certificate:
* <cert-details-cut-off>
*  SSL certificate verify ok.
*   Certificate level 0: Public key type RSA (2048/112 Bits/secBits), signed using sha256WithRSAEncryption
*   Certificate level 1: Public key type RSA (3072/128 Bits/secBits), signed using sha256WithRSAEncryption
*   Certificate level 2: Public key type RSA (4096/152 Bits/secBits), signed using sha256WithRSAEncryption
* Connected to foo.bar (my_ip) port 443
* using HTTP/1.x
} [5 bytes data]
> GET /grafana/d-solo/feizqmmy116gwe/?orgId=1&from=2026-04-12T09:22:17.007Z&to=2026-05-12T10:22:17.007Z&panelId=1 HTTP/1.1
> Host: foo.bar
> User-Agent: curl/8.14.1
> Accept: */*
> Authorization: Bearer ***
>
* Request completely sent off
{ [5 bytes data]
* TLSv1.3 (IN), TLS handshake, Newsession Ticket (4):
{ [57 bytes data]
* TLSv1.3 (IN), TLS handshake, Newsession Ticket (4):
{ [57 bytes data]
< HTTP/1.1 200 OK
< Date: Fri, 15 May 2026 10:48:52 GMT
< Server: Apache/2.4.67 (Debian)
< Cache-Control: no-store
< Content-Type: text/html; charset=UTF-8
< X-Content-Type-Options: nosniff
< X-Frame-Options: deny
< X-Xss-Protection: 1; mode=block
< Vary: Accept-Encoding
< Transfer-Encoding: chunked
<
{ [3860 bytes data]
<!DOCTYPE html>
<html lang="en-US">
  <head>

    <meta charset="utf-8" />
    <meta http-equiv="X-UA-Compatible" content="IE=edge,chrome=1" />
    <meta name="viewport" content="width=device-width" />
    <meta name="theme-color" content="#000" />

    <title>Grafana</title>
...

but when trying to rung rendering via panel Share link option image renderer seems to have issue with accessing Grafana and in fact generates PNG but with such content:
- foo-bar1000×500 34.1 KB

What did you expect to happen?
- Generate PNG with panel

Can you copy/paste the configuration(s) that you are having problems with?

here is my grafana.ini

[server]
domain = foo.bar
protocol = http
root_url = https://foo.bar/grafana
[rendering]
rendering_mode = remote
server_url = http://localhost:8081/render
callback_url = https://foo.bar/grafana/
renderer_token = test-token
rendering_dumpio = true

here is my Apache config from /etc/apache2/conf-available/apache-grafana.conf

<IfModule proxy_module>
    ProxyRequests Off
    <Proxy *>
        <IfVersion >= 2.4>
            Require all granted
        </IfVersion>
        <IfVersion < 2.4>
            Order deny,allow
            Allow from all
        </IfVersion>
    </Proxy>

    ProxyPass /grafana http://localhost:3000 status=+I
    ProxyPassReverse /grafana http://localhost:3000 status=+I
    ProxyPass /api http://localhost:3000/api status=+I
    ProxyPassReverse /api http://localhost:3000/api status=+I
    ProxyPreserveHost On

    SSLProxyMachineCertificateFile /etc/ssl/certs/foo-bar-proxy.pem
</IfModule>

here is my docker config from docker-compose.yml

services:
  renderer:
    image: grafana/grafana-image-renderer:latest
    container_name: grafana-image-renderer
    restart: unless-stopped
    network_mode: host
    environment:
      LOG_LEVEL: debug
      RENDERING_VERBOSE_LOGGING: 'true'
      AUTH_TOKEN: test-token
      HTTP_HEADERS: '{"Authorization":"Bearer ***"}'

Did you receive any errors in the Grafana UI or in related logs? If so, please tell us exactly what they were.
- Nothing particular
Did you follow any online instructions? If so, what is the URL?
- Yes, the one to setup image rendered

Thank you in advance for any hints!

Szymon

infofcc3 · May 18, 2026, 11:22am

szymontrocha · May 18, 2026, 11:42am

Hi,

I think, as I wrote above, I followed that document carefully. Is there a particular thing I’m missing form it?

Sz.

infofcc3 · May 18, 2026, 12:07pm

please check
serve_from_sub_path = true in grafana.ini file
then
restart
sudo systemctl restart grafana-server
docker restart grafana-image-renderer
sudo systemctl restart apache2

szymontrocha · May 18, 2026, 2:38pm

Please note this option should only be set when proxy is not used (see documentation page). In my case setting it results in a browser error too many redirects.

yosiasz · May 18, 2026, 5:07pm

@infofcc3 It is good to carefully read what people are asking and maybe try to reproduce the issue locally like the OP setup as @szymontrocha very nicely laid out.
