Using Grafana for application mapping

[ldb]

I want to use Grafana to make an application mapping. So i want to know if there is a way to do it with a plugin or with a native way.

Thanks

[yosiasz]

Welcome to forum

Something like this ?

[ldb]

Yes something like that

[mikhailvolkov]

You can do it using native Node Graph panel

Node graph | Grafana documentation

Alternative is Apache ECharts for more customization options and event handling

Build directed graph in Grafana using Apache ECharts | Tutorial part 1

[ldb]

Whaat plugin did you use ?

[jangaraj]

I would say your “application mapping” is service graph, which is generated from traces:

Service graph view | Grafana Tempo documentation

[robertonorton]

@ldb

I want to use Grafana to make an application mapping. So i want to know if there is a way to do it with a plugin or with a native way.

Hii
You can create application mappings in Grafana using plugins, custom dashboards, or by integrating with third-party tools like Prometheus or Jaeger for metrics and traces visualization. Choose the method that suits your needs best.
