Infinity data source - Grafana meta data header not working via yml

Grafana
1

Hi everyone,

I’m trying to provision a datasource via YAML with dynamic headers (like explained here URL | Grafana Plugins documentation ), but it works only when configured via the GUI and not via YAML.

The part of my datasource yml file:

- name: infinity
type: yesoreyeram-infinity-datasource
url: "http://example.com/"
isDefault: false
basicAuth: false
jsonData:
httpHeaderName1: "user_email"
secureJsonData:
httpHeaderValue1: ${__user.email}

The value remains empty in the header. When doing the same manually via the GUI, it is working. Checking the grafana database, I see that there is an encrypted value for httpHeaderValue1, even for the YAML case.

2
3

When I query the data source via the API, I get the following for the one created via the GUI:

jsonData:
httpHeaderName1: "user_email"
secureJsonFields:
httpHeaderValue1: true

When querying the provisioned data source, I get either no secureJsonFields at all, when doing ‘httpHeaderValue1: ${__user.email}’ in the YAML file

jsonData:
httpHeaderName1: "user_email"
secureJsonFields:

Or the same “true” (but still no value in the header), when doing ‘httpHeaderValue1: “${__user.email}”’ in the YAML file

jsonData:
httpHeaderName1: "user_email"
secureJsonFields:
httpHeaderValue1: true

4

I guess it should be secureJsonData. Try that, pls.

1 Like
5

check docu also

6

The “secureJsonFields” is just the output of the HTTP API. The datasource.yml has jsonData and secureJsonData. In general, static strings are working via the datasource.yml, just not these meta data / variables.

7

Thank you, I exactly did this Provisioning | Grafana Plugins documentation and URL | Grafana Plugins documentation

Like shown above, I tried in the YAML file the following and tried with and without ‘, “, |, <<>> around the variable.

jsonData:
httpHeaderName1: "user_email"
secureJsonData:
httpHeaderValue1: ${__user.email}

1 Like
8

Double $$? Provision Grafana | Grafana documentation

1 Like
9

Yes, $$ is working. Thank you, Sriram.
