Simple JSON API & Dashboard Variables don't appear to work

Grafana Configuration
1
  • What Grafana version and what operating system are you using?

Grafana Cloud Version 9

  • What are you trying to achieve?

I’m trying to add variables to a dashboard using an JSON feed → https://services.nvd.nist.gov/rest/json/cves/1.0?

  • How are you trying to achieve it?

I go to the dashboard that I want to add a variable too. I create the variable using the following param using SimpleJSON as my API.

Datasource = https://services.nvd.nist.gov/rest/json/cves/1.0?
Field = $.result.CVE_Items[*].cve.CVE_data_meta.ID

This returns a list of the data I want my dashboard to filter on.

I add this to the dashboard but when I select a particular CVE at random, it doesn’t get applied to any of the underlying tables. It’s almost like the variable is not dynamic.

  • What happened?

As above.

  • What did you expect to happen?

I should be to filter on the data that I want only to show.

  • Can you copy/paste the configuration(s) that you are having problems with?

  • Did you receive any errors in the Grafana UI or in related logs? If so, please tell us exactly what they were.

N/A

  • Did you follow any online instructions? If so, what is the URL?

NA/

2

how are the underlying queries using this variable? can you please share?

3

I presume you mean this? See image.

query1
query11550×749 45.2 KB

As you can see, I’m just doing something very basic at the moment. I’m polling the data and looking to just view CVE-2022-32561. I’m yet to append any additional fields.

4

does not look like you are using the variable (from the drop down) anywhere in your A query. having a variable in of itself does not mean it will do something as far as I understand it. you have to use it in your queries

5

Hmmm there doesn’t appear to be any viable option to add this. Not at least using this Simple JSON api.

6

take a look at this, it should help out

https://marcus.se.net/grafana-json-datasource/query-editor#params

7

Thanks for the advice. I feel like what I’m trying to do isn’t possible with using the Simple JSON api. I’ll keep playing around and see if I can work it out.

8

hi louisleedavies,
would you use a variable in queries to filter data successfully?
I use JSONPath to query data: $.result.item[?(@.Name==“$variable”)].value
but I still got no data

9

Welcome

I would highly recommend using infinity plugin and also maybe try out jsonata query language

Can you please post sample json data you are trying to filter?

1 Like
10

Glad to hear from you.
In this case, I want to display ‘SeismicIntensity’ in different regions by selecting different ‘StationName’.

Sample json data：
{
“records”: {
“Earthquake”: [
{
“EarthquakeNo”: 112033,
“Intensity”: {
“ShakingArea”: [
{
“EqStation”: [
{
“StationName”: “Hehuanshan”,
“SeismicIntensity”: “3”
},
{
“StationName”: “Shetou”,
“SeismicIntensity”: “4”
}
]
},
{
“EqStation”: [
{
“StationName”: “Taichaung”,
“SeismicIntensity”: “5”
},
{
“StationName”: “Tainan”,
“SeismicIntensity”: “3”
}
]
}
]
}
},
{
“EarthquakeNo”: 112034,
“Intensity”: {
“ShakingArea”: [
{
“EqStation”: [
{
“StationName”: “Nantou”,
“SeismicIntensity”: “4”
},
{
“StationName”: “Taidong”,
“SeismicIntensity”: “2”
}
]
},
{
“EqStation”: [
{
“StationName”: “Taipei”,
“SeismicIntensity”: “3”
},
{
“StationName”: “Yilan”,
“SeismicIntensity”: “6”
}
]
}
]
}
}
]
}
}

Steps：
First, I create a variable(named as StationName) by using JSONPath:
$.records.Earthquake[].Intensity.ShakingArea[].EqStation[*].StationName

Then, I create a panel in dashboard and query the data by using JSONPath:
$.records.Earthquake[].Intensity.ShakingArea[].EqStation[?(@.StationName==“$StationName”)].SeismicIntensity

But It returns no data.
it only displays all data by using JSONPath:
$.records.Earthquake[].Intensity.ShakingArea[].EqStation[*].SeismicIntensity

1 Like
11

please properly format the json blob of data you posted?

12

sorry, I format the data.

{
	"records": {
		"Earthquake": [
			{
				"EarthquakeNo": 112033,
				"Intensity": {
					"ShakingArea": [
						{
							"EqStation": [
								{
									"StationName": "Hehuanshan",
									"SeismicIntensity": "3"
								},
								{
									"StationName": "Shetou",
									"SeismicIntensity": "4"
								}
							]
						},
						{
							"EqStation": [
								{
									"StationName": "Taichaung",
									"SeismicIntensity": "5"
								},
								{
									"StationName": "Tainan",
									"SeismicIntensity": "3"
								}
							]
						}
					]
				}
			},
			{
				"EarthquakeNo": 112034,
				"Intensity": {
					"ShakingArea": [
						{
							"EqStation": [
								{
									"StationName": "Nantou",
									"SeismicIntensity": "4"
								},
								{
									"StationName": "Taidong",
									"SeismicIntensity": "2"
								}
							]
						},
						{
							"EqStation": [
								{
									"StationName": "Taipei",
									"SeismicIntensity": "3"
								},
								{
									"StationName": "Yilan",
									"SeismicIntensity": "6"
								}
							]
						}
					]
				}
			}
		]
	}
}
1 Like
13

image1524×530 72.7 KB

This is using infinity plugin, using jsonata. If you want to select multiple from the drop down you use this UQL query with jsonata

parse-json
| jsonata "$.records.Earthquake.Intensity.ShakingArea.EqStation[StationName in [${stationname:singlequote}]][]"

if you want to use one station at a time you use

| jsonata "$.records.Earthquake.Intensity.ShakingArea.EqStation[StationName = '$stationname'][]"
1 Like
14

I solved it.
Really grateful to you for your help!!

1 Like
