Azure storage account not connecting

Grafana Tempo
1

I am trying to set up tempo in an AKS cluster using this values.yaml with federated token

tempo:
  mode: distributed
  storage:
    trace:
      blocklist_poll_tenant_index_builders: 1
      blocklist_poll_jitter_ms: 500
      backend: azure
      blocklist_poll: 5m
      azure:
        container_name: <container-name>
        storage_account_name: <storage-account-name>
        use_federated_token: true
      pool:
        max_workers: 400
        queue_depth: 20000
      search:
        prefetch_trace_count: 1000
      wal:
        path: /var/tempo/wal


  serviceAccount:
    name: tempo
    annotations:
      azure.workload.identity/client-id: ""
    labels:
      azure.workload.identity/use: "true"

  image:
    tag: "2.8.1"

  searchEnabled: true

  compactor:
    extraArgs:
      - -config.expand-env=true
    extraEnv:
      - name: AZURE_CLIENT_ID
        value: ""

  ingester:
    extraArgs:
      - -config.expand-env=true
    replicaCount: 3
    extraEnv:
      - name: AZURE_CLIENT_ID
        value: ""

  querier:
    extraArgs:
      - -config.expand-env=true
    replicaCount: 2
    extraEnv:
      - name: AZURE_CLIENT_ID
        value: ""

  memberlist:
    join_members:
      - tempo-gossip-ring:7946

traces:
  otlp:
    grpc:
      enabled: true
    http:
      enabled: true

distributor:
  log_received_spans:
    enabled: true
  log_discarded_spans:
    enabled: true
  extraArgs:
    - -config.expand-env=true
  receivers:
    otlp:
      protocols:
        grpc: 0.0.0.0:4317
        http: 0.0.0.0:4318
  extraEnv:
    - name: AZURE_CLIENT_ID
      value: ""
  service:
    type: LoadBalancer
    ports:
      - name: otlp-grpc
        port: 4317
        targetPort: 4317
      - name: otlp-http
        port: 4318
        targetPort: 4318
      - name: http-metrics
        port: 3200
        targetPort: 3200
      - name: grpc-metrics
        port: 9095
        targetPort: 9095


queryFrontend:
  extraArgs:
    - -config.expand-env=true
  service:
    type: LoadBalancer
    ports:
      - name: http-query
        port: 3200
        targetPort: 3200
      - name: grpc-query
        port: 9095
        targetPort: 9095
  extraEnv:
    - name: AZURE_CLIENT_ID
      value: ""

I am able to connect to grafana and send traces to tempo but they only stay for a bit. So when i checked the config map it showed the storage backend to be local instead of azure

 storage:
      trace:
        backend: local
        blocklist_poll: 5m
        local:
          path: /var/tempo/traces
        pool:
          max_workers: 400
          queue_depth: 20000
        search:
          prefetch_trace_count: 1000
        wal:
          path: /var/tempo/wal

Tried editing the config map from local to azure, then the pods starts crashing with this error


level=error ts=2025-08-18T10:12:26.996639065Z caller=main.go:121 msg="error running Tempo" err="failed to init module services: error initialising module: store: failed to create store: getting storage container: no client ID specified. Check pod configuration or set ClientID in the options".

what is the problem here?

2
3

I managed to get mine to connect. At the end of my values file I added

tempo:

serviceAccountName:

and then I also had to setup my azure storage like this:

trace:

  backend: azure

azure:

container_name:

storage_account_name:

use_federated_token: true

use_managed_identity: false

I did build my storage container ahead of time but that isn’t of consequence
