Recently, I configured Docker log collection and container monitoring using Grafana. This setup provides both logs and performance metrics in dashboard, making Docker monitoring much easier.
Architecture
Docker Logs
Docker Containers → Promtail → Loki → Grafana
Docker Metrics
Docker Containers → cAdvisor → Prometheus → Grafana
Collecting Docker Logs with Promtail
Promtail automatically discovers Docker containers and sends logs to Loki. Container information such as container name, container ID, image name, and host name can be added as labels. This makes log filtering very easy inside Grafana.
Benefits
• Centralized Docker logs
• Search logs by container name
• Filter logs by host
• Easy troubleshooting
• Real-time log monitoring
Grafana Dashboard for Docker Logs
I created a Grafana dashboard to visualize Docker container logs.
Key features:
• Total log count
• Error log count
• Warning log count
• Live log viewer
• Host filter
• Container filter
A custom Container variable was added so users can quickly select a specific container and view only its logs.
Configure Promtail for Docker Logs
server:
http_listen_port: 9080
positions:
filename: /tmp/positions.yaml
clients:
- url: http://LOKI_SERVER:3100/loki/api/v1/push
scrape_configs:
- job_name: docker
docker_sd_configs:
- host: unix:///var/run/docker.sock
refresh_interval: 5s
relabel_configs:
- source_labels: \['\__meta_docker_container_name'\]
regex: '/(.\*)'
target_label: 'container'
replacement: '$1'
- source_labels: \['\__meta_docker_container_id'\]
target_label: 'container_id'
- source_labels: \['\__meta_docker_container_image'\]
target_label: 'image'
- target_label: 'job'
replacement: 'docker'
- target_label: 'host'
replacement: 'SERVER_NAME'
pipeline_stages:
- docker: {}
Verify Promtail
systemctl status promtail
Check logs:
journalctl -u promtail –f
Monitoring Docker Metrics with cAdvisor
For container performance monitoring, I deployed cAdvisor. It collects Docker container metrics and exposes them to Prometheus.
Metrics collected include:
- Total container count
- Container status
- CPU usage per container
- Memory usage per container
- Network traffic per container
Grafana Dashboard for Docker Metrics
The metrics dashboard provides a quick overview of container health and performance.
Dashboard panels include:
- Running containers
- Container uptime
- CPU utilization
- Memory consumption
- Network traffic
- Container status overview
This helps identify resource-heavy containers and monitor overall Docker environment health.
Install cAdvisor
cAdvisor collects Docker container metrics such as CPU, Memory, Network, and Container Status.
docker run -d \\
--name cadvisor \\
-p 8081:8080 \\
-v /:/rootfs:ro \\
-v /var/run/docker.sock:/var/run/docker.sock:ro \\
-v /sys:/sys:ro \\
-v /var/lib/docker:/var/lib/docker:ro \\
--restart unless-stopped \\
--privileged \\
gcr.io/cadvisor/cadvisor:v0.49.1
Verify:
docker ps
Open:
http://SERVER_IP:8081
Configure Prometheus
Add cAdvisor target.
scrape_configs:
- job_name: cadvisor
static_configs:
- targets:
- SERVER_IP:8081
Reload Prometheus:
systemctl restart prometheus
Verify target:
http://PROMETHEUS_IP:9090/targets
Target should show UP.
Add Prometheus Data Source in Grafana
Navigate:
Grafana → Connections → Data Sources
Add:
Prometheus
URL:
http://PROMETHEUS_IP:9090
Build Docker Monitoring Dashboard
Conclusion
Using Promtail, Loki, Grafana, Prometheus, and cAdvisor together creates a complete Docker monitoring solution. Logs and metrics are available in one place, making troubleshooting faster and improving visibility into Docker environments.
